• USB 4-Wire Touch screen controller
• Item Condition：
• New
• Warranty：
• One Month Warranty
• Part Description：
• 1x Driver Installation Disk
• Part Number：
• USB 4-Wire Touch screen controller
• Part Info1：
• 1x USB Touch Panel Controller Board
• Part Info2：
• 1x Controller Board to USB port/jack cable
• Product Weight：
• 120

Product Content

Touch Screen Controller  communicates with PC system connects directly through USB cable- Pluge in to the USB port or solder to the USB jack.


 It supports:
Microsoft Windows Vista, Windows XP,2000,95/98
Windows Me, NT4.0,CE2.12 & 3.0/ NET ,DOS


?Circuit Board Dimension:20mm x 68mm (0.79inches x 2.68inches)----(4-Wire)
?Power Requirements：D.C.+5V (100mA typical,50mV peak to peak maximum ripple and noise)
?Operating Temperature：0 to 50 ℃
?Storage Temperature：-40 to 80 ℃
?Relative Humidity：95% at 60 ℃
?Interface：USB 1.1 Low Speed
?Report rate：USB Model: Max. 160 points/sec
?Response time：Max. 35 ms
?Panel resistance:4 wire resistive model: 300 ~ 900 ohm!
?Outlet in order: X +, Y +, X-, Y-


Features:
4 points Positioning
25 points positioning
Support right mouse button
Support drawing line test
Multi-language operating window
Support multiple Monitors
With the visual rotation




Package Contents:


1x Driver Installation Disk
1x USB Touch Panel Controller Board
1x Controller Board to USB port/jack cable
