• New Desktop PC Motherboard DDR2 RAM Memory PCIE Slot Diagnostic Repair Test Tester Card with LED Light
• Item Condition：
• New In Orginal Packing
• Warranty：
• One Month Warranty
• Product Brand：
• HUB
• Part Description：
• 1pcs * DDR2 RAM PCIE Slot Diagnostic Tester Card
• Part Number：
• DDR2 RAM PCIE Diagnostic Tester Card
• Product Weight：
• 100

Product Content

Destop computer Mainboard Board DDR RAM Memory Slot tester:

Through the process of starting up ond read the RAM Memory, could indicate the faults in the mother board circuit for further repairing.
The fault could be reflected  by the LED light, indicating open circuit or short circuit or data line and address line.



Usage:

Install the 3.3v(CR2032) battery on the tester, mainboard need not power on, press the button of the tester.
If the LEDs all light on and the brightness are all the same, the signal is all right ,there is no problem.
No light Or weak light signals there is problem, you should refer to sign indication beside that LED light
