• Mini PCI Diagnostic Analyzer. 4 Digit Display
• Item Condition：
• New
• Warranty：
• One Month Warranty
• Part Description：
• Mini PCI Diagnostic Analyzer. 4 Digit Display
• Part Number：
• Post Card with 25 Pin
• Part Info1：
• 60x60x15mm thick
• Part Info2：
• 1 x Mini PCI Diagnostic Analyzer.
• Part Info3：
• 1 x USB cable
• Part Info4：
• 1 x English Full User Guide
• Product Weight：
• 65

Product Content

Laptop Mainboard Board DDR RAM Memory Slot tester.

?Through the process of starting up and read the RAM Memory, could indicate the faults in the mother board circuit for further repairing.
?The fault could be reflected  by the LED light, indicating open circuit or short circuit or data line and address line.



Usage:

?Install the 3.3v (CR2032) battery on the tester, mainboard need not power on, press the button of the tester.
?If the LEDs all light on and the brightness are all the same, the signal is all right ,there is no problem.
?No light Or weak light signal there is problem, you should refer to sign indication beside that LED light
