• Laptop Motherboard DDR2 RAM Memory Slot Diagnostic Analyzer Tester Card with LED
• Item Condition：
• New
• Warranty：
• One Month Warranty
• Part Description：
• 1pcs* DDR 2 DDR2 RAM Memory Slot Tester With LED Indicator
• Part Number：
• Checking open or short circuit or data line
• Part Info1：
• 68 x 40 x 28mm
• Part Info2：
• DDR 2 RAM Memory Slot Tester
• Product Weight：
• 6

Product Content

Laptop Mainboard Board DDR RAM Memory Slot tester.

Through the process of starting up and read the RAM Memory, could indicate the faults in the mother board circuit for further repairing.
The fault could be reflected  by the LED light, indicating open circuit or short circuit or data line and address line.



Usage:

Install the 3.3v (CR2032) battery on the tester, mainboard need not power on, press the button of the tester.
If the LEDs all light on and the brightness are all the same, the signal is all right ,there is no problem.
No light Or weak light signal there is problem, you should refer to sign indication beside that LED light
