• 1.6" LCD Display PCI PC PTI6 Diagnostic Analyzer Card Intel 9xx Ix Motherboard Post Tester
• Item Condition：
• New
• Warranty：
• One Month Warranty
• Part Description：
• PCI Diagnostic Post Card, 1.6" LCD Display
• Part Number：
• Button for BIOS or PAGE Dispaly
• Part Info1：
• 75x63x6mm thick
• Part Info2：
• 1 x PCI Diagnostic Post Card,
• Part Info3：
• 1 x English user quide
• Product Weight：
• 25

Product Content

Diagnostic Post Card with attached LCD screen to shows error code and reasons

?The most easy way for enthusiasts and engineers to test and repair computer.
?Inserts into the PCI slot and sets button to dispaly BIOS or Page before booting.
?Supports AMI, Award & Phoenix.
?Supports English language.
?CLK, SYS, +5V, +3.3V LED light indicators

Tested For Motherboard Chipset INTEL 815,INTEL 845,INTEL 865,INTEL 915,INTEL 945，INTEL 965，ATI SB600,ATI Xpress 200,ATI Xpress 1100,AMD 480X ect..

1. ASUS P7P55D：Test for INTEL LGA 1156 series Core i7, Core i5 CPU Processor， Intel P55 series Chipset.


2. HP DC7100 915G Motherboard：LGA 775 Celeron D CPU Processor , Integrated Sound/Network Card.


3. ASUS P6T: Test for INTEL LGA 1156 Series Core i7 CPU Processor， Intel X58 Series Chipset.


4. Lenovo 760G Motherboard M3A760M Dual-core CPU Processor , Support for AM3 with HDMI DDR3.


5. ASUS P5Q: Test for INTEL LGA 775 Series, Core2 Duo , Pentium D Celeron D CPU Processor， Intel P45 Series Chipset.


6.  DELL Optix GX280 775 Pin I915G+ICH6.


7. ASUS M2N_SLI: Test for AMD AM2 940 Series CPU Processor , nVIDIA 560 Series Chipset


8. ASUS STRIKER: Test for INTEL LGA 7750 Series CPU Processor  , NVIDIA78i Series Chipset


9. ASUS P5N7:  Test for INTEL LGA 775 Series Conroe,Pentium D,Celeron D CPU processor , nVIDIA 560 Series Chipset


10. ASUS P6T:  Test for INTEL LGA 1156 Series , Core i5 CPU Processor， Intel X58 Series Chipset
